MBR Membrane Bioreactor Compacted Systems MBR Residential
Wastewater Treatment Systems
Product Description
MBR is a new type of high-efficiency sewage treatment process that
combines high-efficiency membrane separation technology with
traditional activated sludge method. The unique MBR flat sheet
membrane module is placed in the aeration tank, and after aerobic
aeration and biological treatment The water is then pumped out
after being filtered through the filter membrane by a pump. The
membrane separation equipment is used to intercept the activated
sludge and macromolecular organic matter in the biochemical
reaction tank, eliminating the need for a secondary settling tank
and greatly increasing the concentration of activated sludge.
MBR integrated equipment is an integrated equipment that uses
membrane bioreactor (MBR) for sewage treatment and reuse. It has
all the advantages of membrane bioreactors: good effluent water
quality, low operating costs, strong system impact resistance, and
sludge Small quantity and high degree of automation. In addition,
as an integrated device, it has a small footprint and is easy to
integrate. It can not only be used as a small sewage reuse
equipment, but also as the core processing unit of a larger sewage
treatment plant (station). It is currently one of the hotspots in
the field of sewage treatment and has broad application prospects.
Technical Parameters
| Item | Inlet water quality(mg/l) | Outlet water standard(mg/l) |
| COD | <2380 - 8942 | <30-75 |
| BOD | <600-850 | <50 |
| TSS | <189 - 3330 | <25 |
| PH | 6.7 | 6.5~8.5 |
| O&G | 215 | <10 |
Main Features
MBR wastewater treatment specification is the combination of a
membrane process like micro filtration or ultrafiltration with a
suspended growth bioreactor, and is now widely used for municipal
and industrial wastewater treatment.The main features of our MBR
include: high quality outlet, lower running cost, high adjust
ability, less sludge outcome, automate operation and less land
occupied. It can be used both for a small complete wastewater
treatment system and a post-treatment for a large wastewater
treatment plant.
The device is characterized by the stable performance, effective
treatment, economical investment, automatic operation, convenience
of maintenance and small occupying space. There is no need for
plant construction, neither heating and heat preservation. The
surface can be used as green land or square land.
Application
1. Production and domestic sewage treatment;
2. Sewage treatment in urban residential quarters;
3. Distributed domestic sewage treatment for schools, hotels,
scenic spots, farmhouses, etc.;
4. Small sewage treatment projects such as high-speed service
areas, railway stations, airports, hospitals, etc. Rural areas;
FAQ
Q1: can you make a quotation? Do you have a price list?
A1: Yes, we will reply to you within 24 hours. yes.
Q2: how many payment methods are there?
A2: we can accept electronic transfer and other payment methods.
Q3: how does the company guarantee thequality?
A3: we have a professional quality control team to check the
products of our factory.
Q4: is the product customizable?
A4: yes.
