Good Price Biological Treatment Intergrated Sewage Treatment
Equipment Container For Residential/Schools/Villages/Hotels
Product Description
MBR integrated equipment is an integrated equipment that uses
membrane bioreactor (MBR) for sewage treatment and reuse. It has
all the advantages of membrane bioreactors: good effluent water
quality, low operating costs, strong system impact resistance, and
sludge Small quantity and high degree of automation. In addition,
as an integrated device, it has a small footprint and is easy to
integrate. It can not only be used as a small sewage reuse
equipment, but also as the core processing unit of a larger sewage
treatment plant (station). It is currently one of the hotspots in
the field of sewage treatment and has broad application prospects.
According to different inlet water quality and outlet water quality
standards, the integrated process flow and equipment configuration
will be different, as follows: MBBR, MBR series of products for
reference. At the same time, according to the needs of users, we
can customize the integrated sewage treatment equipment suitable
for the user's watewater characteristics.
Technical Parameters
| Item | Inlet water quality(mg/l) | Outlet water standard(mg/l) |
| COD | <2380 - 8942 | <30-75 |
| BOD | <600-850 | <50 |
| TSS | <189 - 3330 | <25 |
| PH | 6.7 | 6.5~8.5 |
| O&G | 215 | <10 |
working principle
MBR reaction tanks loaded hollow fiber membrane, microbial reaction
vessel sewage biodegradability of pollutants in the assimilation
and alienation.Most alienation productinto harmless CO2 and H2O,
assimilate an integral substance of microorganisms. Film unit
primarily to solid-liquid separation, the solid can be effectively
microbes trapped in the reactor, to ensure the stability of water
quality.
Sewage through the sewage pipe network to sewage treatment station,
the first through the screen canal, skimming large particlesof
suspended solids and impurities; and then into the sewage
Equalization tank, homogenizing sewage, water regulation in the
Equalization tank, the sewage from the sewage lift pump up to
anoxic tank.
Sewage in the anoxic tank, denitrification process, to achieve
further nitrogen removal.Anoxic tank effluent into the aeration
tank, the treated effluent into the MBR reaction tank after the
level of aerobic treatment.
Main Features
1.With nitrogen and phosphorus removal ability and equipment
structure adjustability which can achieve different wastewater
treatment.
2.The media in the contact oxidation tank is mostly combined soft
media, light weight, high strength, stable physical and chemical
properties.The specific surface area is larger, the biofilm
adhesion ability is strong, and the contact efficiency between the
sewage and the biofilm is high.
3,In the contact oxidation tank, an aerator is used for blast
aeration, so that the fiber bundle is continuously floated and the
aeration is uniform.Good for microbial growth and maturity, with
the characteristics of activated sludge method.
4. The outlet quality is stable, the sludge production is small and
easy to handle.
5. Submersible pumps can be placed in the equipment, reducing
engineering investment.
6.The equipment can be located on the ground, but also buried
underground, meanwhile the upper cover can be used for greening.
7.Can achieve automatic control, simple management.
